♦ Security / burglarproof. Can't break in under normal tools, strike, or lift.
♦ Afforable. Steel roller shutter garage door are cheaper than aluminum roller garage door.
♦ Long service life. Steel roller shutter garage door is made of rolled forming slats, which makes the garage door more strong and with long life service.
♦ Automatic operation by remote control, wall-mounted switch button.
♦ Manual operation: There is a manual hoist chain on the motor, in case of power off, you could still open/close the garage door by manual hoist chain.
♦ Nice appearance. The steel roller shutter garage door could be powder coatet to any standard RAL color to meet your design requirement to match the surroundings.
| Item model | Max width | Max height | Color | Operation way | Options |
| MT012 | 7,000 mm | 7,000 mm | any RAL color by powder coating | manual operation, motorized operation | shutter box, safety sensor, UPS, Anti-drop safety brake, video surveillance |
The rolling garage door curtain itself consists of Consisted of interlocking steel blades/slats, with steel end clips on both sides of curtain to prevent lateral movement.
Thickness option: 0.6mm, 0.8mm, 1 mm,1.2mm
Blade / Slat options: from 82mm to 110 mm pitch height, we always have the slats that suit your garage best.
Bottom rail (with EPDM rubber weather real):
♦Material: galvanized steel
♦With plastic end caps on both sides
♦With EPDM rubber weather seal to prevent the dust, rain, insects from coming inside.
Guide rail (optional with rubber):
♦Material: galvanized steel
♦Dimension: from 70mm to 100 mm width
♦Thickness available: from 1.2 mm to 3 mm thickness
♦Optional: With brush inserted on both sides of the guide rail, to make the door runs more quietly and smoothly.
Shaft / Axle:
♦Material: galvanized steel
♦Diameter: 3 inches, 5 inches, 6 inches, 8 inches, 10 inches
♦Wall thickness: 1.5 mm, 2 mm, 2.5 mm, 3 mm, 4 mm
Mullions: Removable center mullions are available on request for applications were shutter opening can’t be covered by one shutter door.
Side plates / brackets
♦The brackets are manufactured from mild steel and supplied in premed finish
♦The brackets can only be installed on a structural fixing surface such as concrete, steel columns, steel angles are normally used to supported the brackets if needed
♦With plates slotted to accommodate shaft or motor mounting.
Operation way:
♦Manual operation by hand or hook (push up & push down)
♦Automatic operation with motor(remote controls, switch button)
Optional:
♦Shutter box / hood cover
♦Perforated slats, punched slats are available if needed. When choosing shutters for a garage unit, a popular option is to have some perforated slats or punched slats in the middle / top of the door curtain, which will allow airflow / ventilation, however, they still offer a high level of security.
♦Wicket door
Warranty / Guarantees:
All of our doors are fully compliant and CE marked. They come with a comprehensive 5 years warranty.
